Bolted Steel Waste Water Storage Tanks for Wastewater Treatment Project

Why the municipal sewage treatment plant choose Bolted Steel Wastewater Storage Tanks and Effluent Holding Tanks?

The service life is more than 30 years with a lower maintenance, Glass-Fused-to-Steel is two materials - Enamel glaze and steel plate surface are fused together after heat treatment at 850-940ºC and then create a tough and inert bond, which combines the strength of steel with the outstanding chemical and physical corrosion resistance of glass. Then it is easy to install , dismantled, removed and relocated,Glass-Fused-To-Steel tank is assembled by Glass-Fused-To-Steel plate and fixed by self - locking bolt. Then the sealing glue is applied to the joint gap and bolt position to improve airtightness of the tank. Also tank's color can be customized ,which enable Glass Lined Steel Municipal sewage storage tank better integrate with the surrounding environment. That is why so many municipal sewage treatment plant choose Glass-Fused-to-Steel Tank as the municipal sewage storage tank.

Share:

Glass Lined Steel Water Storage Tanks Accessories

The Glass Fused To Steel Tanks are delivered as a complete package.

The standard set of waste water storage tanks include:

1. Glass fused to steel sheets

2. Self - Locking Bolts

3. Sealant


WasteWater Treatment Project Equipment Supply

Pretreatment EquipmentResource Utilization SystemSludge Treatment SystemOther Equipment
Mechanical Bar ScreenSolid-liquid SeparatorSubmersible MixerGas HolderBoiler SystemBoost FanBiogas GeneratorTorch SystemDehydration and Desulfurization TankPAM Integration Dosing DeviceScrew Sludge Dewatering MachineSlurry Separation CentrifugeSewage PumpMud ScraperSubmersible Sewage PumpThree-phases Separator

Glass Fused-To-Steel Water Storage Tanks Specifications

Coating colorDark blue, Dark green, White, and customized
A standard steel plate sizeeffective size 2400mm x 1200 m
Steel plates thickness3mm - 12mm , depends on the diameter & height
Coating thickness0.25mm - 0.4mm, two coating internal and external
Acid and alkalinity proofstandard coating suits for PH3 - PH11, special coating suits for PH1 - PH14
Adhesion3,450N/cm
Elasticsame as steel sheet , around 500KN/mm
Hardness6.0 Mohs
Service life>30 years
Spark/Holiday test>1500 V
Permeabilitygas and liquid impermeable
Easy yo cleansmooth, glossy, inert, anti-adhesion
Corrosion resistanceexcellent ! Suitable for waste water salt water, sea water, high sulfur crude oil, salt fox, organic and inorganic compounds
