Hebei Wansheng Environmental Protection Engineering Co., Ltd. strictly implements the AWWA-D103-09 standard in tank structure design. It usually adopts a cylindrical vertical structure with stable structure and uniform force. The tank capacity, diameter, height and wall thickness are determined according to the water storage demand, and the force needs to be combined with parameters such as water pressure, wind load, and seismic load;

GFS bolted tanks consist of glass fused to steel plates, special sealing material, self-locking screws and other materials.

The widely used thickness of enamel steel plate ranges from 3 to 10 mm, even reaching to a maximum of 20 mm. lf the steel plate has oil on the surface, containing rust and oxide skin, after shot blasting and other pre-treatment process, the steel plate surface will be cleaned. After firing at 820℃-930'℃, so the enamel coating(0.25-0.4mm) is fused to the surface of steel plate to formula inert and inorganic barrier on both the interior and exterior sides of the steel plates, which combines both strength and flexibility of steel and excellent corrosion resistance of glass as well as the perfect impact and abrasion resistance, and that withstands the extreme temperature and harsh weather conditions.

Professional installation supervision engineers are responsible for installation guidance on site to ensure installation quality;

Provide professional supporting installation tools;
